ISO 3894, SAE J267, GB/T5909-2009, GM W14341, TUV, SAE j328, ISO 3006, QC／T 221, GB／T 5334-2005
Automotive Testing Equipment Applicable Industry
Widely used in various automotive, wheel and material research institutes, quality inspection institutes, academic institutions, automobile manufacturing manufacturing, and wheel manufacturing manufacturing bending fatigue tests.
Automotive Testing Equipment Technical Parameters
| 1 | Position number | 2 |
| 2 | Test wheel type | Passenger Car Wheel |
| 3 | Structure | Horizontal machine with temperature insulation room |
| 4 | Test wheel specification: |
| Test wheel diameter range | 13〞-24〞 |
| Test wheel width | 5〞-8.5〞 |
| Wheel offset | 0-60 mm |
| Tyre diameter range | Max. 900 mm |
| 5 | Drum size: |
| Diameter | 1707.6 mm |
| Width | 450 mm |
| Surface roughness | ≤ 3.2μm |
| Radial run-out accuracy | ≤ 0.25 mm |
| Residual imbalance | ≤ 5g |
| 6 | Load range | Pos. 1# Max. 50KN | Pos. 2# Max. 30KN |
| Load accuracy | ±1 % |
| Loading method | Mechanical servo in closed-loop control |
| 7 | Speed range | 40-120km/h |
| Speed control method | Automatic or manual, AC closed-loop control |
| Digital counter capacity | 1.0*107 r |
| 8 | Cooling system/blast system | used for cooling during work, and it also has the function of dust extraction. |
| 9 | Soundproofing system | Included |
| 10 | Safety cover | For protect the machine n operator during work |
| 11 | power supply | AC 380 V±10 % |
| 12 | Power frequency | 50 Hz±2 % |
| 13 | Working temperature | 10℃～40℃ |
| 14 | Environment humidity | ≤85% |
Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services. Free Non-consumable components will be provided if any performance failure occurs within 12 months, caused by non-human damage.
Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.
Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).15 years focusing on test instruments field. Six years exporting experience, warmly welcome to visit our plant (factory), we also support OEM and ODM.
Q4: After an order is placed, when to deliver?
A: Generally about 15 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.
Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely.Each of the instruments must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. Engineers would be to go abroad for training and repairing.
Q6: What about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
